A fastening assembly consisting of a bolt and an expansion sleeve that anchors into substrates by expanding against the hole wall.
●Material: Q195
●Finish: Blue Zinc
●Grade: 4.8
●Installation hole diameter(mm): 8, 10, 12, 14
| Finish | Material | Grade | Installation hole diameter | Bolt Length | Sleeve Length | Range of substrate thickness | Limit range of substrate thickness | Weight | Size | Application |
|---|---|---|---|---|---|---|---|---|---|---|
| Blue Zinc | Q195 | 4.8 | 8 | 39 | 32 | 5-7mm | 3-12mm | 6.4g | 4*32 | hollow bricks, gypsum boards, and wooden boards |
| 8 | 45 | 38 | 12-14mm | 10-16mm | 7.3g | 4*38 | ||||
| 8 | 53 | 46 | 19-21mm | 16-24mm | 8.4g | 4*46 | ||||
| 8 | 60 | 52 | 22-24mm | 18-28mm | 9.4g | 4*52 | ||||
| 10 | 45 | 37 | 8-10mm | 6-13mm | 11g | 5*37 | ||||
| 10 | 60 | 52 | 12-14mm | 3-16mm | 14.1g | 5*52 | ||||
| 10 | 72 | 65 | 26-28mm | 15-32mm | 16.9g | 5*65 | ||||
| 10 | 88 | 80 | 40-43mm | 28-45mm | 21g | 5*80 | ||||
| 12 | 45 | 37 | 8-10mm | 6-13mm | 14.9g | 6*37 | ||||
| 12 | 60 | 52 | 12-14mm | 3-16mm | 19.3g | 6*52 | ||||
| 12 | 72 | 65 | 25-27mm | 14-32mm | 23.4g | 6*65 | ||||
| 12 | 88 | 80 | 40-42mm | 28-45mm | 27.8g | 6*80 | ||||
| 14 | 45 | 37 | 8-10mm | 6-13mm | 22.6g | 8*37 | ||||
| 14 | 60 | 52 | 12-14mm | 3-16mm | 28.2g | 8*52 | ||||
| 14 | 72 | 65 | 25-27mm | 14-32mm | 34.9g | 8*65 | ||||
| 14 | 88 | 80 | 40-42mm | 28-45mm | 41.3g | 8*80 |
